Polaris 180 Parts Diagram

Polaris 180 Parts Diagram

Check the parts blowup above for the most common replacement part for the Polaris 180 Pool Cleaner.  The parts list below shows the most common part replacement along with any substitutions that could be used.



Diagram # Sku Image Title Price Quantity for Product # to Add to Cart Actions
1 A16
Polaris A16 All Purpose Debris Bag $54.53 1
3 A5
Polaris A5 Top Housing Replacement $58.17 1
4 A20
Polaris A20 Float, Head $9.60 1
4 25563-120-000
CMP 25563-120-000 Pool Cleaner White Generic Hose Float $9.07 1
5 9-100-3105
Polaris 9-100-3105 Sweep Hose Scrubber $4.99 1
5 R0522400
Polaris R0522400 Sweep Hose Scrubber for Cleaners 3 pack $14.80 1
7 B5
Polaris B5 Sweep Hose Complete $46.42 1
8 B10
Polaris B10 Wear Rings, Pack of 5 $3.34 8
9 B15
Polaris B15 Sweep Hose Attach Clamp $3.54 1
11 C66
Polaris C66 Large Axle with Sand/Gravel Guard $12.52 2
13 C45
Polaris C45 Lock Washer For C36 280/180 - 5 pack $4.50 1
15 C60
Polaris C60 Ball Bearing, Wheels $12.34 8
16 C6
Polaris C6 Large Wheel without Bearing Replacement $10.42 3
17 C10
Polaris C10 Tire, Maxtrax, 380/360/280/180 $17.87 3
18 C64
Polaris C64 Plastic Wheel Washer for Polaris 280/180 $2.78 4
19 C55
Polaris C55 Plastic Wheel Screw $1.86 4
20 C65
Polaris C65 Rear Wheel Large Axle Replacement $6.24 1
21 C131
Polaris C131 Thrust Jet Kit $6.51 1
22 C16
Polaris C16 Idler Wheel, Single-Side $12.74 1
23 C30
Polaris C30 Screw 4-40 x 3/16" SS Pan Head for Polaris Cleaners $3.49 1
24 C32
Polaris C32 6-32 x 0.5" Screws 5-Pack $2.51 1
25 C25
Polaris C25 Spring Replacement for C36 Polaris Cleaners $2.99 1
26 C36
Polaris C36 Swing Axle Kit for 280/180 $20.50 1
29 C80
Polaris C80 Ball Bearings, Turbine for Polaris 280/180 $22.22 2
31 C86
Polaris C86 Drive Shaft Assembly for Polaris 280/180 $44.46 1
38 10-112-00
Polaris 10-112-00 UWF Restrictor Disk Kit 180/280/380 $4.99 1
39 6-500-00
Polaris 6-500-00 Universal Wall Fitting $7.99 1
40 9-100-9001
Polaris 9-100-9001 UWF Connector Assembly $41.98 1
41 10-108-00
Polaris 10-108-00 UWF Restrictor Kit PVS $9.80 1
42 6-504-00
Polaris 6-504-00 Universal Wall Fitting In-Line Filter Screen $12.00 1
43 6-505-00
Polaris 6-505-00 Universal Wall Fitting and Quick Disconnect O-Ring Replacement $2.70 1
44 9-100-9002
Polaris 9-100-9002 Pressure Relief Valve $13.18 1
46 ED15
Pentair ED15 Legend Feed Hose Mender Nut $11.08 46
46 D15
Polaris D15 Nut, Feed Hose $3.99 1
48 D20
Polaris D20 Ball Bearing Swivel for Pool Cleaners $15.20 2
50 D45
Polaris D45 Feed Hose Section (10 feet, White) $39.42 2
54 G57
Polaris G57 Back Up Valve Collar Replacement $12.73 1
55 G53
Polaris G53 Mechanism Replacement $89.85 1
